Class 5 Non-CDL Lube Truck
Our Class 5 Non-CDL Service Lube Trucks allow crews to perform oil changes, fluid service, and routine maintenance directly on jobsites. Built on a Ford F-600 chassis, each unit is equipped with multiple fresh oil tanks, used oil recovery, grease dispensing, compressed air, and a hydraulically powered pressure washer to keep equipment serviced and running in the field.
Our Lube Trucks are available for immediate rental from our locations in Atlanta, GA, Houston, TX, St. Louis, MO, Kansas City, MO, and Olathe, KS. Don’t see your location listed? We can also deliver these trucks anywhere in the continental United States!
Multi-Fluid Tank System
Six onboard product tanks plus a dedicated used-oil tank allow crews to carry multiple fluids in a single truck. Technicians can perform routine service directly on the jobsite without returning to the shop.
Vacuum Oil Extraction System
Sage’s vacuum system pulls used oil directly from equipment without traditional pumps. This allows for faster service while reducing system complexity and maintenance.
Fluid System
Air, Grease & Power Systems
Body, Storage & Work Area
Dimensions & Chassis
- 220-gallon used oil recovery tank
- 120-gallon fresh oil tank
- (2) 100-gallon fresh oil tanks
- (3) 80-gallon fresh oil tanks
- 60-gallon coolant tank
- 10-micron inline filtration on fresh oils
- Vacuum fill system (8–15 gallons per minute)
- Pumpless vacuum and pressure fluid delivery system
- Electronic metered dispensing reels
- PTO-driven Vanair RC40-L air compressor
- 15-gallon air storage tank
- ½" × 50' retractable air hose reel
- 120-lb grease system with 50:1 grease pump
- 3/8" × 50' retractable grease hose reel
- Hydraulically powered pressure washer
- Heavy-duty steel body construction with 3/16" cross members
- Integrated reel cabinet with aluminum roll-up shutter door
- Aluminum underbody toolboxes with gas shocks
- Interior LED lighting in cabinet and storage compartments
- Six adjustable exterior LED flood/spot lights
- Centralized control panel for dispensing and vacuum operations
- LED fluid level indicators
- Integrated used filter receptacle with oil evacuation
- Backup camera integrated with in-dash display
- Heavy-duty aluminum mechanics drawer system
- Class 5 Ford F-600 Chassis (108" cab-to-axle)
- Shipping weight – 15,780 lb
- Maximum operational weight – 18,834 lb
- Overall length – 310 in
- Overall width – 96 in
- Overall height – 106 in
